Equipment Configuration:

Brush holder & brush box riveting rotary table machine

Assembly and inspection unit for brush box thermal protector and grounding strip

Resistance welding station

Carbon brush position detection (CCD vision)

Carbon brush spring force testing station

Brush holder marking + full CCD inspection station

Equipment Working Principle:

The machine adopts a rotary table for multi-station riveting of brush boxes. Multiple processing stations are connected into a complete production line via a speed-multiplying conveyor. The line requires 5 operators.
